Automatic Flexo printing and punching machine for paper cup CCY1080/2-A
| Specifications |
| 1.Maximum diameter of roll:￠1500 mm |
| 2.Maximum width of roll: ￠1080 mm |
| 3.Material:120-380gsm |
| 4.Cutting deviation：±0.25 mm; |
| 5.Cutting speed: Maximum speed up to 300 punching/min (depends on paper size and feed length) |
| 6.Maximum punching area: 1060 × 520 mm. |
| 7.Minimum tooth number of roller gear for flexible press:Z=110 |
| 8.Maximum tooth number of roller gear for flexible press: Z=160 |
| 9.Metric roll circumference: 345.5752-502.6548 mm (pitch CP=π) |
| 10.British system roll circumference:349.25-508 mm（pitch CP=3.175） |
| 11.Max printing width: 1060 mm |
| 12.Total power: 40 Kw |
| 12.Machine size：6,600 × 2,500 × 2,100 mm |
| 13.Voltage:380V/50Hz |
| 14.Machine weight: 6 T |
